AWG23 CCA Copper 4 Pair Lan Cat6 Flat Ethernet Cable For Communication

Name: AWG23 CCA Copper 4 Pair Lan Cat6 Flat Ethernet Cable For Communication
Brand: JiangHong or OEM
Price: 1 USD

Quality AWG23 CCA Copper 4 Pair Lan Cat6 Flat Ethernet Cable For Communication wholesale

Brand Name : JiangHong or OEM

Model Number : SFTP CAT6

Certification : CE/ISO9001/RoHS

Place of Origin : Sichuan,China

MOQ : 100 boxes

Price : US $22-42 / Box

Payment Terms : L/C, D/A, D/P, T/T, Western Union, Western Union

Delivery Time : 5-8Days

Packaging Details : Carton+Pallet

HS Code : 8544491100

Material of conductor : CCA/Copper

Type : SFTP CAT6

Application : Local Communication,Telecommunication, Instrumentation, Networks

Shield : Foil or Foil+Aluminum Magnesium Braid

Color : Customized

Contact Now

SFTP CAT6 AWG23 Communication Cable CCA Copper Fluke Test LAN Cable

DESCRIPTION

Twisting a pair of mutually insulated metal wires in a counterclockwise direction at a certain density can effectively reduce signal interference, and then wrap multiple pairs of twisted pairs into an insulated cable jacket.

FEATURES

Low attenuation, low crosstalk;
wide transmission bandwidth and high transmission rate;

APPLICATIONS

Indoor / Outdoor, For the military, hospitals, banking and financial systems, etc.

Electrical Characteristics
Frequency (MHz)	ATT(≤dB/100m)	NEXT(≥dB)	ELFEXT(≥dB)
1	2.04	62.3	60.0
4	4.1	55.3	49.0
10	6.5	47.3	41.0
20	9.3	42.8	35.0
31.25	11.7	39.9	31.1
62.5	17.0	35.2	25.0
100	22.0	32.3	21.0

AWG23 CCA Copper 4 Pair Lan Cat6 Flat Ethernet Cable For Communication
